3 Axis CNC Turning Center TCK50A CNC Lathe
Product Tags :
CNC lathe manufacturingCNC turningHorizontal CNC Latheautomatic lathecnc lathecnc turning centermini metal lathe
Product Attributes :
ALHAAS CNC Slant bed cnc lathe TCK50A:
Maximum processing length:500mm
Spindle bore:66mm
X/Z axis repeatability:±0.003
Machine dimension(L×W×H):2600*1850*2000
Product Description
The ALHAAS CNC TCK50A CNC lathe machine is a full-featured CNC precision lathe designed and engineered using advanced foreign technology. The design and controls are developed taking into account the requirements of ergonomics: it is convenient and easy to operate, easy to repair.
Product Advantages:
ALHAAS CNC TCK50A CNC Turning Center:
- 7.5/11 kW spindle servo motor maintains a constant cutting speed when changing the machining diameter.
- Large (up to 87 mm) diameter of the hole in the spindle.
- 3-jaw hydraulic chuck Ø 250 mm. as standard. The diameter of the hole in the spindle is 66 mm.
- Rigid tailstock with a one-piece cast body and a quill diameter of 70 mm. The quill is moved by a hydraulic cylinder.
- Plate type conveyor for chip removal.
Product Specifications:
| Specifications | Unit | TCK50A |
| Max.swing over bed | mm | Φ560 |
| Max.swing over cross slide | mm | Φ260 |
| Maximum processing length | mm | 350/500 |
| Spindle motor power | KW | 7,5/11 |
| Highest spindle speed | rpm | 3000 |
| Spindle bore | mm | Φ66 |
| X/Z axis repeatability | mm | ±0,003 |
| Net. weight (about) | kg | 3000 |
